WAW-600D Computer Display Hydraulic Universal Testing Machine
Product description:The machine adopts hydraulic loading, Computer Display, easy and convenient to operate. It is mainly used to execute the tension, compression, bending, flexural etc. test for metal materials.
The machine adopts hydraulic loading, Computer Display, easy and convenient to operate. It is mainly used to execute the tension, compression, bending, flexural etc. test for metal materials. Attached with simple accessories and devices, it can be used to test wood, concrete, cement, rubber, and so on.It is very suitable for making test to different metal or nonmetal materials under high toughness and hardness against extreme big loading force.
ISO6892, BS4449,ASTM C39,ISO75001, ASTM A370, ASTM E4, ASTM E8 and BSEN standards.
|Structure||4 columns and 2 screws|
|Control way||Constant stress uniform deformation constant displacement three closed loop control and program control dealing|
|Deformation Measurement Range||2%～100%FS|
|Displacement resolution (mm)||0.01|
|Max piston moving speed||0-90mm/min stepless speed adjusting|
|Crosshead lifting speed||200mm/min|
|Max. tension test space||650mm (can customize)|
|Max.Compression Test Space||500mm (can customize)|
|Clamping method||Hydraulic clamp|
|Round specimen clamping range (mm)||Φ13-Φ26,Φ26-Φ40, (Φ6-Φ13 , Φ40-Φ50 Optional )|
|Flat specimen clamping range (mm)||0-15 (15-30 Optional)|
|Flat specimen clamping width(mm)||80|
|Compression plate size (mm)||φ160|
|Bending roller distance(mm)||450|
|Width of bending rollers (mm)||120|
|Power supply||3-phase,AC380V, 50Hz（can be customized）|
