WEW-2000D Computer Display Hydraulic Universal Testing Machine

Product description:

The machine adopts hydraulic loading, Computer Display, easy and convenient to operate. It is mainly used to execute the tension, compression, bending, flexural etc. test for metal materials. Attached
  • WAW-H 1000,2000kN Double Cylinder Electro-hydraulic Servo Universal Testing Machine
  • M12、M14、M16、M18、M20、M22、M24、M27、M30 Bolt and Nut Hydraulic Tensile Universal Testing Machine
  • WAW-2000D 2000kN 200Ton Computer Control Electro-hydraulic Servo Universal Testing Machine
  • 200Ton 300Ton Steel Rebar steel strand Electro-hydraulic Single Space Servo Universal Testing Machine With Wedge Grip

Share With:

We"re here to help:
Easy ways to get the answers you need.
Send E-mailChat Now
WEW-2000D Computer Display Hydraulic Universal Testing Machine

Application:

The machine adopts hydraulic loading, Computer Display, easy and convenient to operate. It is mainly used to execute the tension, compression, bending, flexural etc. test for metal materials. Attached with simple accessories and devices, it can be used to test wood, concrete, cement, rubber, and so on.It is very suitable for making test to different metal or nonmetal materials under high toughness and hardness against extreme big loading force.

Standards:

ISO6892, BS4449,ASTM C39,ISO75001, ASTM A370, ASTM E4, ASTM E8 and BSEN standards.

Specifications:

Model WEW-2000D
Structure 4 columns and 2 screws
Control way loading process manual control,computer automatic data dealing
Max.load (kN) 2000kN
Load accuracy ≤±1%
Load range 2%-100%FS
Load resolution 1/300000
Deformation Measurement Range 2%~100%FS
Deformation accuracy ≤±1%
Displacement resolution (mm) 0.01
Displacement error ≤±0.5%
Max.piston stroke(mm) 250
Max piston moving speed 0-90mm/min manual adjustment
Crosshead lifting speed 200mm/min
Max. tension test space 850mm (can customize)
Max.Compression Test Space 650mm (can customize)
Clamping method Hydraulic clamp
Round specimen clamping range (mm) Φ12-Φ30mm, Φ30-Φ50mm, Φ50-Φ70mm
Flat specimen clamping range (mm) 0-35 mm
Flat specimen clamping width(mm) 80
Compression plate size (mm) φ160
Bending roller distance(mm) 450
Width of bending rollers (mm) 120
Power supply 3-phase,AC380V, 50Hz(can be customized)
