HCTM-2000W Frame-type Computer Automatic Compression Testing Machine

Product description:

It is conformed to EN 12390-3, 12390-4; BS 1881,ASTM E4, ASTM C139, ISO7500-1, EN10002-2, BS 1610, DIN51220, C1231 –AASHTO T22 -NF P18-411 -UNE 83304, 7242 etc.
  • HCBT-5000 Electric Cement Bending Test Machine
  • YAW-5000F Computer Control Electro-hydraulic Servo Compression Testing Machine
  • concrete and cement pipe compression test machine
  • YAW-C Computer Control Hydraulic Compression and Bend Testing Machine

Share With:

We"re here to help:
Easy ways to get the answers you need.
Send E-mailChat Now

1. Application

This series compression testing machine is mainly designed for compression test of building material items, such as concrete cube, concrete blocks, cement specimen, and bricks etc, also used for compression performance test of rubber pad and top forge test of metal. With new design idea and advanced technology, this series have more advantages in appearance, operation & applications. It is the ideal test equipment for quality control at industry & mineral enterprises, education in high schools, and technology researches at scientific institutes.

2. Standards:

It is conformed to EN 12390-3, 12390-4; BS 1881,ASTM E4, ASTM C139, ISO7500-1, EN10002-2, BS 1610, DIN51220, C1231 –AASHTO T22 -NF P18-411 -UNE 83304, 7242 etc.

3. Main Specifications

Model

HCTM-2000W

HCTM-3000W

Max. Load

2000kN

3000kN

Control method

Computer auto control loading process

Test space adjustment mode

Electric ball screw adjust

Test class

1 class

Load measuring range

2-100% of F.S

Load accuracy

±1.0%

The roughness value for texture of loading and auxiliary platens

≤ 3.2μm

Distance between columns (mm)

380

Upper compression platen (mm)

300*300

Lower compression platen (mm)

300*300

300*300

Distance between columns(mm)

380

430

Piston stroke(mm)

150

150

Distance between upper and lower plate

320mm

410

Power supply

AC380V/220V

Overall dimension (mm)

1000x420x1550

1350x500x1680

Weight (kg)

1200

1400
